GIS Plug in Terminations Up To 42kv

  • Factory moulded and 100% tested.
  • Dry type.
  • Metal-enclosed and suitable for outdoor use.
  • Optional voltage detection point.
  • Robust with high mechanical properties.
  • In compliance with IEC-60840 & 62271-209.
DOWNLOAD
BROCHURE

Type Table for Single Core Inner Cone Plug In Terminations Size-2, 630/800A

Cable Cross Section (mm2 ) 6.35/11(12) kV 12.7/22 (24) kV 19/33 (36) kV
50 DGISS-2-11/50 DGISS-2-22/50 DGISS-2-33/50
70 DGISS-2-11/70 DGISS-2-22/70 DGISS-2-33/70
95 DGISS-2-11/95 DGISS-2-22/95 DGISS-2-33/95
120 DGISS-2-11/120 DGISS-2-22/120 DGISS-2-33/120
150 DGISS-2-11/150 DGISS-2-22/150 DGISS-2-33/150
185 DGISS-2-11/185 DGISS-2-22/185 DGISS-2-33/185
244 DGISS-2-11/244 DGISS-2-22/244 DGISS-2-33/244
300 DGISS-2-11/300 DGISS-2-22/300 DGISS-2-33/300
400 DGISS-2-11/400 DGISS-2-22/400 DGISS-2-33/400

Type Table for Single Core Inner Cone Plug In Terminations Size-2, 630/800A

Cable Cross Section (mm 2) 6.35/11(12) kV 12.7/22 (24) kV 19/33 (36) kV
50 DGIS-2-11/50 DGIS-2-22/50 DGIS-2-33/50
70 DGIS-2-11/70 DGIS-2-22/70 DGIS-2-33/70
95 DGIS-2-11/95 DGIS-2-22/95 DGIS-2-33/95
120 DGIS-2-11/120 DGIS-2-22/120 DGIS-2-33/120
150 DGIS-2-11/150 DGIS-2-22/150 DGIS-2-33/150
185 DGIS-2-11/185 DGIS-2-22/185 DGISS-2-33/185
244 DGI-2-11/244 DGI-2-22/244 DGI-2-33/244
300 DGI-2-11/300 DGI-2-22/300 DGI-2-33/300
400 DGI-2-11/400 DGI-2-22/400 DGI-2-33/400

Type Table for Single Core, Inner Cone Plug In Terminations Size-3, 1250A

Cable Cross Section (mm2) 6.35/11(12) kV 12.7/22 (24) kV 19/33 (36) kV
50 DGIS-3-11/50 DGIS-3-22/50 DGIS-3-33/50
70 DGIS-3-11/70 DGIS-3-22/70 DGIS-3-33/70
95 DGIS-3-11/95 DGIS-3-22/95 DGIS-3-33/95
120 DGIS-3-11/120 DGIS-3-22/120 DGIS-3-33/120
150 DGIS-3-11/150 DGIS-3-22/150 DGIS-3-33/150
185 DGIS-3-11/185 DGIS-3-22/185 DGIS-3-33/185
240 DGIS-3-11/240 DGIS-3-22/240 DGIS-3-33/240
300 DGIS-3-11/300 DGIS-3-22/300 DGIS-3-33/300
400 DGIS-3-11/400 DGIS-3-22/400 DGIS-3-33/400
500 DGIS-3-11/500 DGIS-3-22/500 DGIS-3-33/500
630 DGIS-3-11/630 DGIS-3-22/630 DGIS-3-33/630

Type Table for 3 Core, Inner Cone Plug In Terminations Size-3, 1250A

Cable Cross Section (mm2) 6.35/11(12) kV 12.7/22 (24) kV 19/33 (36) kV
50 DGIS-3-11/50 DGIS-3-22/50 DGIS-3-33/50
70 DGIS-3-11/70 DGIS-3-22/70 DGIS-3-33/70
95 DGIS-3-11/95 DGIS-3-22/95 DGIS-3-33/95
120 DGIS-3-11/120 DGIS-3-22/120 DGIS-3-33/120
150 DGIS-3-11/150 DGIS-3-22/150 DGIS-3-33/150
185 DGIS-3-11/185 DGIS-3-22/185 DGIS-3-33/185
240 DGIS-3-11/240 DGIS-3-22/240 DGIS-3-33/240
300 DGIS-3-11/300 DGIS-3-22/300 DGIS-3-33/300
400 DGIS-3-11/400 DGIS-3-22/400 DGIS-3-33/400
500 DGIS-3-11/500 DGIS-3-22/500 DGIS-3-33/500
630 DGIS-3-11/630 DGIS-3-22/630 DGIS-3-33/630
